Main technical parameters
| Model | ST-YLS | Model | ST-YLS |
|---|---|---|---|
| Main raw materials | PE, PP | Roller length (mm) | 600 - 900 |
| Screw material | 38CrMoALA | Online twisting and winding machine (Spindles) | 28 - 60 |
| Diameter of screw (mm) | Φ65 - Φ90 | Maximum spindle speed (rpm) | 2300 |
| Screw ratio (L/D) | 33:1 | Motor power (kw) | 0.75 |
| Production capacity (kg/h) | 30 - 125 | Number of twisted threads | 5 - 15 |
| Main motor (kw) | 18.5 - 55 | Installed power (kw) | 130 - 200 |
| Die head specification (mm) | Φ195 - Φ360 | Machine size (L×W×H) m | (28 - 34)×3.2 - 4.5×2.5 |
| Number of spinneret (holes) | Decide according to requirements |
JIANGSU ST MACHINERY MANUFACTURING CO., LTD provides plastic extrusion lines for woven packaging, geotextiles & industrial applications. Energy-efficient, ISO-certified systems with 30+ years of precision engineering expertise. Custom solutions with 24/7 technical support.
